Model | Rated Voltage (V) | Rated Capacity (AH) | Dimensions(mm/in) | Weight ±4%(Kg) | Number of post of the same polarity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Length | Width | Height | Total Height | Dry | wet | Acid weight(d=1.24kg/L) | |||||||||||
mm | in | mm | in | mm | in | mm | in | Kg | Lbs | Kg | Lbs | Kg | Lbs | ||||
CFPS2100 | 2 | 100 | 103 | 4.06 | 206 | 8.1 | 354 | 13.9 | 409 | 16.1 | 8.5 | 18.74 | 13.5 | 29.76 | 5 | 11.02 | 1 |
CFPS2150 | 2 | 150 | 103 | 4.06 | 206 | 8.1 | 354 | 13.9 | 409 | 16.1 | 11 | 24.25 | 15.5 | 34.17 | 4.5 | 9.92 | 1 |
CFPS2200 | 2 | 200 | 103 | 4.06 | 206 | 8.1 | 354 | 13.9 | 409 | 16.1 | 13.5 | 29.76 | 17.5 | 38.58 | 4 | 8.82 | 1 |
CFPS2250 | 2 | 250 | 124 | 4.88 | 206 | 8.1 | 354 | 13.9 | 409 | 16.1 | 16 | 35.27 | 21 | 46.3 | 5 | 11.02 | 1 |
CFPS2300 | 2 | 300 | 145 | 5.71 | 206 | 8.1 | 354 | 13.9 | 409 | 16.1 | 18.5 | 40.79 | 24.5 | 54.01 | 6 | 13.23 | 1 |
CFPS2350 | 2 | 350 | 124 | 4.88 | 206 | 8.1 | 470 | 18.5 | 525 | 20.7 | 21 | 46.3 | 28 | 61.73 | 7 | 15.43 | 1 |
CFPS2420 | 2 | 420 | 145 | 5.71 | 206 | 8.1 | 470 | 18.5 | 525 | 20.7 | 24.5 | 54.01 | 33 | 72.75 | 8.5 | 18.74 | 1 |
CFPS2500 | 2 | 500 | 166 | 6.54 | 206 | 8.1 | 470 | 18.5 | 525 | 20.7 | 26 | 57.32 | 36 | 79.37 | 10 | 22.05 | 1 |
CFPS2600 | 2 | 600 | 145 | 5.71 | 206 | 8.1 | 645 | 25.4 | 700 | 27.6 | 31 | 68.34 | 43 | 94.8 | 12 | 26.46 | 1 |
CFPS2770 | 2 | 770 | 253 | 9.96 | 210 | 8.3 | 472 | 18.6 | 527 | 20.8 | 42.5 | 93.7 | 58 | 127.87 | 15.5 | 34.17 | 1 |
CFPS2800 | 2 | 800 | 191 | 7.52 | 210 | 8.3 | 645 | 25.4 | 700 | 27.6 | 44 | 97 | 60 | 132.28 | 16 | 35.27 | 2 |
CFPS21000 | 2 | 1000 | 233 | 9.17 | 210 | 8.3 | 645 | 25.4 | 700 | 27.6 | 52 | 114.6 | 72 | 158.73 | 20 | 44.09 | 2 |
CFPS21200 | 2 | 1200 | 275 | 10.8 | 210 | 8.3 | 645 | 25.4 | 700 | 27.6 | 62 | 136.7 | 86 | 189.6 | 24 | 52.91 | 2 |
CFPS21500 | 2 | 1500 | 275 | 10.8 | 210 | 8.3 | 795 | 31.3 | 850 | 33.5 | 75 | 165.4 | 105 | 231.49 | 30 | 66.14 | 2 |
CFPS22000 | 2 | 2000 | 399 | 15.7 | 210 | 8.3 | 771 | 30.4 | 826 | 32.5 | 108 | 238.1 | 150 | 330.69 | 42 | 92.59 | 3 |
CFPS22500 | 2 | 2500 | 487 | 19.2 | 212 | 8.4 | 771 | 30.4 | 826 | 32.5 | 130 | 286.6 | 183 | 403.45 | 52 | 114.6 | 4 |
CFPS23000 | 2 | 3000 | 576 | 22.7 | 212 | 8.4 | 771 | 30.4 | 826 | 32.5 | 157 | 346.1 | 220 | 485.02 | 63 | 138.9 | 4 |
LFPS680 | 6 | 80 | 194 | 7.64 | 170 | 6.7 | 205 | 8.07 | 210 | 8.27 | 11.4 | 25.13 | 14 | 30.86 | 2.6 | 5.73 | 1 |
LFPS6100 | 6 | 100 | 260 | 10.2 | 180 | 7.1 | 245 | 9.65 | 250 | 9.84 | 13.6 | 29.98 | 19 | 41.89 | 5.4 | 11.9 | |
LFPS6120 | 6 | 120 | 260 | 10.2 | 180 | 7.1 | 245 | 9.65 | 250 | 9.84 | 15.5 | 34.17 | 22 | 48.5 | 6.5 | 14.33 | |
LFPS6140 | 6 | 140 | 260 | 10.2 | 180 | 7.1 | 245 | 9.65 | 250 | 9.84 | 17.7 | 39.02 | 25 | 55.12 | 7.3 | 16.09 | |
LFPS6140E | 6 | 140 | 307 | 12.1 | 169 | 6.7 | 220 | 8.66 | 225 | 8.86 | 18.2 | 40.12 | 26 | 57.32 | 7.8 | 17.2 | |
LFPS6160 | 6 | 160 | 307 | 12.1 | 169 | 6.7 | 220 | 8.66 | 225 | 8.86 | 18.5 | 40.79 | 27 | 59.52 | 8.5 | 18.74 | |
LFPS6180E | 6 | 180 | 307 | 12.1 | 169 | 6.7 | 220 | 8.66 | 225 | 8.86 | 19.5 | 42.99 | 29 | 63.93 | 9.5 | 20.94 | |
LFPS6180 | 6 | 180 | 321 | 12.6 | 176 | 6.9 | 226 | 8.9 | 229 | 9.02 | 20.5 | 45.19 | 30.5 | 67.24 | 10 | 22.05 | |
LFPS1260 | 12 | 60 | 260 | 10.2 | 168 | 6.6 | 211 | 8.31 | 233 | 9.17 | 15.9 | 35.05 | 20.8 | 45.86 | 4.9 | 10.8 | |
LFPS1280E | 12 | 80 | 306 | 12.1 | 169 | 6.7 | 211 | 8.31 | 233 | 9.17 | 20.7 | 45.64 | 27.5 | 60.63 | 6.8 | 14.99 | |
LFPS1280 | 12 | 80 | 330 | 13 | 171 | 6.7 | 214 | 8.43 | 220 | 8.66 | 20 | 44.09 | 27.8 | 61.29 | 7.8 | 17.2 | |
LFPS12100 | 12 | 100 | 409 | 16.1 | 176 | 6.9 | 225 | 8.86 | 225 | 8.86 | 24.5 | 54.01 | 35 | 77.16 | 10.5 | 23.15 | |
LFPS12120 | 12 | 120 | 485 | 19.1 | 172 | 6.8 | 240 | 9.45 | 240 | 9.45 | 29.4 | 64.82 | 42.5 | 93.7 | 13.1 | 28.88 | |
LFPS12140 | 12 | 140 | 494 | 19.5 | 206 | 8.1 | 209 | 8.23 | 235 | 9.25 | 31.8 | 70.11 | 46.5 | 102.51 | 14.7 | 32.41 | |
LFPS12140A | 12 | 140 | 532 | 20.9 | 207 | 8.2 | 215 | 8.46 | 240 | 9.45 | 32.5 | 71.65 | 48.5 | 106.92 | 16 | 35.27 | |
LFPS12160 | 12 | 160 | 522 | 20.6 | 238 | 9.4 | 218 | 8.58 | 221 | 8.7 | 36.7 | 80.91 | 53.5 | 117.95 | 16.8 | 37.04 | |
LFPS12180 | 12 | 180 | 522 | 20.6 | 238 | 9.4 | 218 | 8.58 | 221 | 8.7 | 41.6 | 91.71 | 60.5 | 133.38 | 18.9 | 41.67 | |
LFPS12180H | 12 | 180 | 522 | 20.6 | 269 | 11 | 220 | 8.66 | 220 | 8.66 | 42.5 | 93.7 | 62.5 | 137.79 | 20 | 44.09 | |
LFPS12200 | 12 | 200 | 521 | 20.5 | 269 | 11 | 203 | 7.99 | 223 | 8.78 | 46.5 | 102.5 | 67.5 | 148.81 | 21 | 46.3 | |
LFPS12220 | 12 | 220 | 521 | 20.5 | 269 | 11 | 203 | 7.99 | 223 | 8.78 | 50.4 | 111.1 | 73.5 | 162.04 | 23.1 | 50.93 |
Q1. Are you a battery manufacturer, and do you produce the plate by yourself?
A: Yes, we are a 20 years professional battery manufacture in Foshan city, Guangdong, China. And we produce the plate by ourselves.
Q2. Can I have a sample order for rechargeable battery?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q3. What about the lead time?
A: About 7 days for stock products, around 20 days for half container products, 30days for 20ft or 40hq full container products.
Q4. How do you ship the goods and how long does it take to arrive?
A: Airline and sea shipping also optional. Ship by sea usually takes 25-35 days to arrive. We have MSDS, test report for safe transport.
Q5. Can i put my logo on the battery?
A: Yes, please inform us formally before our production and provide PDF or AI of your logo design. We welcome sample test so there is no MOQ of logo print.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-5 years warranty to our products.
Q8: What is the shelf life of VRLA battery and how to maintain the battery?
A: The limiting factor of battery’s shelf life is the rate of self-discharge which itself is temperature dependent. VRLA batteries will self-discharge less than 3% per month at 77℉(25℃). VRLA batteries should not be stored for more than 6 months at 77℉(25℃) without recharged. If in hot temperature, recharge it every 3 month. When batteries are taken out of long storage, it recommended to recharge before use.
Q10. Can I do a partial replacement of my batteries?
A: Partial battery replacement of lead acid battery banks is not recommended
Q11. How does your factory control the quality?
A: We adopt IS0 9001 quality system to control the quality. We have Incoming Quality Control (IQC) department to test and confirm raw material meets high quality producing requirements, Production Quality Control ( PQC) department contains the first Inspection, In-process quality control, acceptance inspection and full inspection, Outgoing Quality Control (OQC) department confirm no defective batteries come out from the factory.
