     POLY SOLAR MODULE 156’ 270-290W



     POLY SOLAR MODULE 156’ 270-290W 2POLY SOLAR MODULE 156’ 270-290W 3





    Product Feature       POLY SOLAR MODULE 156’ 270-290W 4

           ● Bypass diode minimizes the power drop by shade.

           ● The conversion efficiency of solar cell is above 18%.

           ● White tempered glass, EVA resin, weather proof film and anodized aluminum frame to provide efficient protection from the severest environmental conditions.

           ● Waterproof Perfect for grid applications.

           ● Product guarantee 10 years.



    Quality Assurance  POLY SOLAR MODULE 156’ 270-290W 5

         ● Electrical Insulation test             ● Outdoor exposure test

         ● Hot-spot endurance test            ● UV-exposure

         ● Thermal cycling test                   ● Humidity freeze test

         ● Damp heat Test                        ● Robustness of terminations test

         ● Wet leakage current test            ● Mechanical load test

         ● Hail impact test                           ● Bypass diode thermal test



    Physical Specification  POLY SOLAR MODULE 156’ 270-290W 6

         Dimesion:1640*992*35MM         Weight:18.5KG/PCS           Packing: Each box capacity: 31 pcs





    Electrical Characteristics  POLY SOLAR MODULE 156’ 270-290W 7

         POLY SOLAR MODULE 156’ 270-290W 8



    Electric Performance Typical Performance Characteristics POLY SOLAR MODULE 156’ 270-290W 9

    Short Circuit Current Temperature Coefficient %/℃  0.041
    Open Circuit Voltage Temperature Coefficient %/℃  -0.393
    Maximum Power Temperature Coefficient %/℃ -0.310
    Performance Warranty: 90%output:12 years; 80%output:25 years
